6m-12m Galvanized pole steel material
The 6m-12m galvanized pole use high quality Q235 Q345 etc.steel. Smooth surface of lamp pole
Description
Introduction
The galvanized pole street lighting have a hot-dip galvanized anti-corrosion treatment. Secondly, our products are sprayed with high-quality outdoor pure polyester plastic powder, and they are very smooth to the touch. Finally, our products are cheap and high-quality, which is deeply loved by our customers.
Feature
The 6m-12m galvanized pole street lighting pole combine optical performance, energy efficiency and versatility to meet the needs of any field. Secondly, it features an easy-to-maintain motorized door and 3G vibration-rated construction. Finally, our product is extremely durable, with a die-cast aluminum housing with a deep bronze polyester powder-coated finish to ensure corrosion resistance and heat dissipation, and to maintain the lamp's long life.
YL-19-SAP-05001-12001
Technical parameters
|
Shape |
Conoid ,Multi-pyramidal,Columniform,polygonal or conical |
|
Material |
Usually Q345B/A572,minimum yield strength>=345n/mm2Q235B/A36,minimum yield strength>=235n/mm2As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52 |
|
Torlance of dimenstion |
-0.02 |
|
Surface treatment |
Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required. |
|
Standard |
Octagonal tapered column Certified by SIRIM QAS INTERNATIONAL. Approved by JABATAN KERJA RAYA MALAYSIA. Conforms to Standard: Pole design : BS EN 40 Material : BS EN 10025 S275 / JIS G3101 SS400 Welding : BS 5135 Galvanizing : BS 729 / ISO 1461 ASTM A 123 |
|
Length of per section |
Within 14m once forming without slip joint. |
|
Suit for |
Highway Roadway Residential subdivisions Commercial development |
|
Option |
Height from 6m to 12m Flange mounted or planted type Variable arm length from 0.125m to 3.0m with single or double arm type Variable spigot size from 35mm to 60mm. |
|
Production Process |
Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages |
Structure drawing
1.Material
Q235B/A36, minimum yield strength≥235n/mm2. As well as hot rolled coil from Q460, ASTM573, GR65, GR50, SS400, SS490ST52.
2.Finishing
Hot dip galvannized following ASTM A 123, color polyester power or any other standard by clientr equired.
3.Anchor bolt
Should be adjusted based on the real local geological condition.
Detail picture
|
|
|
|
|
|
|
Application
|
|
|
|
Common Specifications of Galvanized Pole
| Height(m) | Top Dia(mm) | Bottom Dia(mm) | Thickness(mm) | Flange plate(mm) | Anchor Bolt(mm) |
| 3m | φ76 | φ112 | 3 | 220*220*12 | 150*150*10-M10 |
| 4m | φ76 | φ124 | 3.5 | 220*220*12 | 150*150*10-M10 |
| 5m | φ76 | φ136 | 3.75 | 240*240*14 | 180*180*12-M12 |
| 6m | φ60 | φ126 | 2.75 | 250*250*12 | 210*210*14-M14 |
| 7m | φ60 | φ137 | 3 | 300*300*16 | 210*210*14-M14 |
| 8m | φ60 | φ148 | 3 | 300*300*16 | 210*210*14-M14 |
| 9m | φ70 | φ170 | 3.5 | 350*350*20 | 250*250*16-M18 |
| 10m | φ70 | φ185 | 3.75 | 350*350*20 | 250*250*16-M18 |
| 11m | φ76 | φ197 | 4 | 350*350*20 | 250*250*16-M18 |
| 12m | φ76 | φ207 | 4 | 400*400*25 | 300*300*18-M20 |
| 13m | φ80 | φ226 | 4 | 400*400*25 | 300*300*18-M20 |
| 14m | φ80 | φ236 | 4 | 400*400*25 | 300*300*18-M20 |
FAQ
(1)Q: What trade terms we do?
A: For most countries, we accept all trade terms.
(2)Q: What kind Payment terms we do?
A:T/T, L/C for the first time. We accept currency: USD, RMB,Swiss Franc,dkk,euro,pound,Rupiah,Indian rupee,yen,Korean Won,Ringgit,NOK,new zealand dollar,Philippine peso,Serbian Dinar,Saudi Riyal,SEK,thb,SINGAPORE DOLLAR,YTL,RAND.
(3)Q: Delivery time?
A: Normally is 7-10days with stock with standards requirements. Special requirements will take around 15-20days depend on the quantity.
(4)Q: Sample policy?
A: All samples of complete lights/pole are not free. Standard sample delivery time: within 1 week. Special samples or OEM requirements takes about 10~14days.
(5)Q: What is our Pole products policy?
A: Every project poles are unique. With your drawings our support will be clear and fast. It is mostly welcomed to know your requirements, such as installation climates, projects requirements, lights quanitty and weight, wind speed...We can design Poles for you.
